B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8
© 2011 Binary
pg.7
3. INSTALLATION
3.1 Installation Considerations
Binary HDMatrix switchers are designed with unsurpassed technology to provide superior
performance. However, where you install the switcher can have a large effect on the
performance that you receive, and the life of the unit. Here are some guidelines to follow
when installing a B-100- HDMatrix Switcher.
• Be sure that the unit is in a well-ventilated area that provides adequate cooling.
• Do not block the cooling vents located on both sides of the unit.
• Do not place the unit on carpeting or any similar material.
• Do not install the unit near a source of heat, or in an extremely humid or wet location.
• If your installation lacks good air flow (such as solid cabinet doors or wall-mounted
racks), it may be necessary to create ventilation to allow outside air into the space.
• Allow a minimum of 3” of free air space on either side of the unit. (Does not apply to
rack mounting)
• Allow a minimum of 2” of depth behind unit to accommodate cables and connectors.
• When placing on a cabinet shelf, position the unit with all feet resting on a
solid level surface.
3.1.1 Rack Installation
The B-100-HDMATRIX can be mounted in a rack with the front or rear panel facing outward.
This allows for easy access to the connections for installations that do not require the
front panel of the unit to be accessed. When mounting the rear panel facing out, it is
recommended that an IR receiver or control system is used.
