IAI America ICS(P)A User Manual
Page 36
ICS(P)A Cartesian Robot, 3-axis Configuration X-Y (Gantry) + Z Type
ICS(P)A3-G
S-CT-SC X-axis/Y-axis: Cable Track, Y-axis/Z-axis: Self-supporting Cable
Drawing No.
GMM08-014
4/4
17
[10] Connector box
[12] Box cover
[13] Connector joint for cable
inside cable track and
controller-actuator cable
[11] Joint cover
M3 x 12 mm (4 pcs)
M3 x 12 mm (4 pcs)
Spacer
S1: M4 x 40 mm
S2/S3: M4 x 16 mm
Follow “Instruction for Cable Track Type Wiring (Drawing No. GMM12-001)”
for how to lay out the wiring inside a cable track.
