SWITCH 1 = LOOP ALL SPIELS (1 = ON)
SWITCH 2 = CLOCK ENABLED (1 = ON)
SWITCH 3 = SELECT SPIEL FROM AUX PORT (1 = ON)
SWITCH 4 = PARITY ENABLED (1 = ON)
SWITCH 5 = MUTE AUDIO WHILE STOPPED (1 = ON)
SWITCH 6 = JUMP FORWARD ON EARLY STARTS (1 = ON)
SWITCH 7 = BANK EARLY STARTS (1= ON)
SWITCH 8 = GO BACK ON EARLY STARTS (1 = ON)
¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥
Reset to Default Configuration:
This switch should only be used when an Audio Repeater wonÕt boot for love or money. When
Dipswitch one, switch 2 is turned on when the card is powered up, the card will revert to the default
configuration. This will allow you to bring up a card when the configuration has been scrambled to such
an extent that it wonÕt let the card boot. This default configuration, although loaded into RAM, wonÕt be
transferred into the EEPROM until you perform any action which will save the memory. These include
eXiting the serial port configuration mode (answering ÔyesÕ when asked if you want to save the
configuration), or doing any of the dipswitch configuration commands.
Be sure to turn this switch back off when you are through with it. Otherwise it will load the default
configuration every time the card is powered up.
