- 5 KHz Bandwidth
(11,718 Hz UPDATE RATE) -
EPROM:
27C512
27C010
27C020
27C040
27C080
SIZE:
64K x 8
128K x 8
256K x 8
512K x 8
1M x 8
Number of bytes per EPROM:
65,536
131,072
262,144
524,28
1,048,576
1
EPROM (1 DR-50 MiniRepeater)
5.59
11.18
22.37
44.74
89.48
2
EPROMs
11.18
22.37
44.74
89.48
178.96
3
EPROMs
16.78
33.55
67.11
134.22
268.44
4
EPROMs
22.37
44.74
89.48
178.96
357.91
5
EPROMs
27.96
55.92
111.85
223.70
447.39
6
EPROMs
33.55
67.11
134.22
268.44
536.87
7
EPROMs
39.15
78.29
156.59
313.17
626.35
8
EPROMs
44.74
89.48
178.96
357.91
715.83
9
EPROMs
50.33
100.66
201.33
402.65
805.31
10
EPROMs
55.92
111.85
223.70
447.39
894.78
11
EPROMs
61.52
123.03
246.07
492.13
984.26
12
EPROMs
67.11
134.22
268.44
536.87
1,073.74
13
EPROMs
72.70
145.40
290.81
581.61
1,163.22
14
EPROMs
78.29
156.59
313.17
626.35
1,252.70
15
EPROMs
83.89
167.77
335.54
671.09
1,342.18
16
EPROMs
89.48
178.96
357.91
715.83
1,431.66
Each Expansion:
32
EPROMs
178.96
357.91
715.83
1,431.66
2,863.31
Repeater + 1 Expansion:
48
EPROMs
268.44
536.87
1,073.74
2,147.48
4,294.97
Repeater + 2 Expansions:
80
EPROMs
447.39
894.78
1,789.57
3,579.14
7,158.28
Repeater + 3 Expansions: 112
EPROMs
626.35
1,252.70
2,505.40
5,010.80
10,021.59
Repeater + 4 Expansions: 144
EPROMs
805.31
1,610.61
3,221.23
6,442.45
12,884.90
Repeater + 5 Expansions: 176
EPROMs
984.26
1,968.53
3,937.05
7,874.11
15,748.21
Repeater + 6 Expansions: 208
EPROMs
1,163.22
2,326.44
4,652.88
9,305.76
18,611.52
Repeater + 7 Expansions: 240
EPROMs
1,342.18
2,684.35
5,368.71
10,737.42
21,474.84
- 7.5 KHz Bandwidth
(17,578 Hz UPDATE RATE) -
EPROM:
27C512
27C010
27C020
27C040
27C080
SIZE:
64K x 8
128K x 8
256K x 8
512K x 8
1M x 8
Number of bytes per EPROM:
65,536
131,072
262,144
524,288
1,048,576
1
EPROM (1 DR-50 MiniRepeater)
3.73
7.46
14.91
29.83
59.65
2
EPROMs
7.46
14.91
29.83
59.65
119.30
3
EPROMs
11.18
22.37
44.74
89.48
178.96
4
EPROMs
14.91
29.83
59.65
119.30
238.61
5
EPROMs
18.64
37.28
74.57
149.13
298.26
6
EPROMs
22.37
44.74
89.48
178.96
357.91
7
EPROMs
26.10
52.20
104.39
208.78
417.57
8
EPROMs
29.83
59.65
119.30
238.61
477.22
9
EPROMs
33.55
67.11
134.22
268.44
536.87
10
EPROMs
37.28
74.57
149.13
298.26
596.52
11
EPROMs
41.01
82.02
164.04
328.09
656.18
12
EPROMs
44.74
89.48
178.96
357.91
715.83
13
EPROMs
48.47
96.94
193.87
387.74
775.48
14
EPROMs
52.20
104.39
208.78
417.57
835.13
15
EPROMs
55.92
111.85
223.70
447.39
894.78
16
EPROMs
59.65
119.30
238.61
477.22
954.44
Each Expansion:
32
EPROMs
119.30
238.61
477.22
954.44
1,908.87
Repeater + 1 Expansion:
48
EPROMs
178.96
357.91
715.83
1,431.66
2,863.31
Repeater + 2 Expansions:
80
EPROMs
298.26
596.52
1,193.05
2,386.09
4,772.19
Repeater + 3 Expansions: 112
EPROMs
417.57
835.13
1,670.27
3,340.53
6,681.06
Repeater + 4 Expansions: 144
EPROMs
536.87
1,073.74
2,147.48
4,294.97
8,589.93
Repeater + 5 Expansions: 176
EPROMs
656.18
1,312.35
2,624.70
5,249.40
10,498.81
Repeater + 6 Expansions: 208
EPROMs
775.48
1,550.96
3,101.92
6,203.84
12,407.68
Repeater + 7 Expansions: 240
EPROMs
894.78
1,789.57
3,579.14
7,158.28
14,316.56
