AA-07-01
Evolver 202 Robotic Atomizers - Parts Identification
8 7 8 7 8 7 8 7 8 7
Applicator Head (Cont.) Applicator Head (Cont.) Applicator Head (Cont.) Applicator Head (Cont.) Applicator Head (Cont.)
RME-32 Seal 4
79151-00 Assembly, Needle Shaft 1
79001-01 O-Ring, Solvent Proof 8
79001-04 O-Ring, Solvent Proof 2
79001-05 O-Ring, Solvent Proof 2
79001-06 O-Ring, Solvent Proof 8
79001-07 O-Ring, Solvent Proof 4
79001-08 O-Ring, Solvent Proof 4
79001-09 O-Ring, Solvent Proof 6
79001-14 O-Ring, Solvent Proof 2
79001-16 O-Ring, Solvent Proof 6
79001-28 O-Ring, Solvent Proof 2
79001-29 O-Ring, Solvent Proof 2
79001-31 O-Ring, Solvent Proof 2
79153-65R-1 Air Cap, Pinned 0-3
79185-48-1
EMF-195
Nozzle, Fluid (8) Hole 0-3
79183-00
79140-02
Fluid Tip, 0.055" Diameter 0-3
79182-03
79154-00
Retaining Ring, Tapered 2
79137-00 Head, Machined, Robot Applicator 1
75777-XX Applicator Covers Accessory
13076-13 O-Ring, .566" OD X .426" ID, Teflon 2
79146-00 Seal, Rear Piston 1
7723-06 Piston, U-Cup 1
79138-XX Complete Spray Head 1
EVOL EVOL EVOL EVOL EVOLVER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SPARE P ARE P ARE P ARE P ARE PAR AR AR AR ARTS (Per Applicator) TS (Per Applicator) TS (Per Applicator) TS (Per Applicator) TS (Per Applicator)
(Cont.) (Cont.) (Cont.) (Cont.) (Cont.)
Part # Part # Part # Part # Part # Description Description Description Description Description Q t y . Q t y . Q t y . Q t y . Q t y .
