Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 25)

AA-07-01 2 0 2 0 2 0 2 0 2 0
Evolver 202 Robotic Atomizers - Installation
Tubing Material Tubing Material Tubing Material Tubing Material Tubing Material Tubing Size Tubing Size Tubing Size Tubing Size Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 1/4" OD X .170" ID
B.A Bearing Air Return Yellow Nylon 1/4" OD X .170" ID
BRK Brake Air Orange Nylon 1/4" OD X .170" ID
DL1 Dump Line #1 Natural Teflon 3/8" OD X 1/4" ID
DL2 Dump Line #2 Natural Teflon 3/8" OD X 1/4" ID
F.O. Fiber Optic Cable Natural Polyethylene 1/4" OD (Jacket)
LV Low Voltage Cable Black N/A N/A
P1.IN Paint #1 In Natural Teflon See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart
P1T Paint #1 Trigger Green Nylon 5/32" OD X .106" ID
P1D Paint #1 Dump Silver Nylon 5/32" OD X .106" ID
P2.IN Paint #2 In Natural Teflon See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart
P2T Paint #2 Trigger Natural Nylon 5/32" OD X .106" ID
P2D Paint #2 Dump Black Nylon 5/32" OD X .106" ID
S.A/A.A Shaping Air (Atomizer Air) Gray Nylon 3/8" OD X .275" ID
S.IN Solvent In Natural Teflon 1/4" OD X .125" ID
SL.A/F.A Seal Air (Fan Air) Blue Nylon 3/8" OD X .275" ID
ST Solvent Trigger Signal Blue Nylon 5/32" OD X .106" ID
T.A Turbine Air Green Nylon 3/8" OD X .275" ID
SIGNAL SIGNAL SIGNAL SIGNAL SIGNAL IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICATION T TION T TION T TION T TION TABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH)
Abbr. Abbr. Abbr. Abbr. Abbr. Description Description Description Description Description Color Color Color Color Color
Tubing Material Tubing Material Tubing Material Tubing Material Tubing Material Tubing Size Tubing Size Tubing Size Tubing Size Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 6mm OD X 4mm ID
B.A Bearing Air Return Yellow Nylon 4mm OD X 2mm ID
BRK Brake Air Orange Nylon 6mm OD X 4mm ID
DL1 Dump Line #1 Natural Teflon 10mm OD X 8mm ID
F.O. Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P1.IN Paint #1 In Natural Teflon See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart
P1T Paint #1 Trigger Green Nylon 5/32" OD X .106" ID
P1D Paint #1 Dump Silver Nylon 5/32" OD X .106" ID
P2.IN Paint #2 In Natural Teflon See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart See Tubing Bundle Assy. Chart
P2T Paint #2 Trigger Natural Nylon 5/32" OD X .106" ID
P2D Paint #2 Dump Black Nylon 5/32" OD X .106" ID
S.A/A.A Shaping Air (Atomizer Air) Silver Nylon 10mm OD X 8mm ID
S.IN Solvent In Natural Teflon 6mm OD X 4mm ID
SL.A/F.A Seal Air (Fan Air) Blue Nylon 8mm OD X 6mm ID
ST Solvent Trigger Signal Blue Nylon 5/32" OD X .106" ID
T.A Turbine Air Green Nylon 10mm OD X 8mm ID
DL2 Dump Line #2 Natural Teflon 10mm OD X 8mm ID
SIGNAL SIGNAL SIGNAL SIGNAL SIGNAL IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICATION T TION T TION T TION T TION TABLE (METRIC) ABLE (METRIC) ABLE (METRIC) ABLE (METRIC) ABLE (METRIC)
Abbr. Abbr. Abbr. Abbr. Abbr. Description Description Description Description Description Color Color Color Color Color
