Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 46)

AA-07-01 4 1 4 1 4 1 4 1 4 1
Evolver 202 Robotic Atomizers - Maintenance
Figure 12: Mounting Block, Shroud Halves, and Retaining Ring Removal Figure 12: Mounting Block, Shroud Halves, and Retaining Ring Removal Figure 12: Mounting Block, Shroud Halves, and Retaining Ring Removal Figure 12: Mounting Block, Shroud Halves, and Retaining Ring Removal Figure 12: Mounting Block, Shroud Halves, and Retaining Ring Removal
33
4
5
7
2
8
2 9
10
1
6
11
12
1 LSFA0027-00 Screw, Retaining #10-32 x 1.50" 4
2 79001-06 O-Ring, Solvent Proof 2
3 77524-00 Screw, Machined, RMA-101 Break-Away 2
4 77523-00 Upper Shroud, Machined, RMA-101 1
5 77522-00 Lower Shroud, Machined, RMA-101 1
6 78976-00 Mounting Ring, RMA-202 1
7 78979-00 Mounting Ring Cover, RMA-202 1
8 79001-14 O-Ring, Solvent Proof 1
9 79001-04 O-Ring, Solvent Proof 1
10 79184-00 Plate, Retention 1
11 A11916 Upper Manifold, Evolver 202 1
12 79103-XX Valve Manifold Assembly, RMA-202 1
Item # Item # Item # Item # Item #
MOUNTING BLOCK, SHROUD HAL MOUNTING BLOCK, SHROUD HAL MOUNTING BLOCK, SHROUD HAL MOUNTING BLOCK, SHROUD HAL MOUNTING BLOCK, SHROUD HALVES, AND RET VES, AND RET VES, AND RET VES, AND RET VES, AND RETAINING AINING AINING AINING AINING
RING REMOV RING REMOV RING REMOV RING REMOV RING REMOVAL AL AL AL AL - P - P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 12) (Figure 12) (Figure 12) (Figure 12) (Figure 12)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
