AA-07-01 3 8 3 8 3 8 3 8 3 8
Evolver 202 Robotic Atomizers - Maintenance
7 79147-00 Nut, Piston 1
8 7723-06 Piston, U-Cup 1
9 79145-00 Plate, Piston 1
10 79144-00 Shaft, Air Valve 1
11 79001-28 O-Ring, Solvent Proof 1
12 79001-29 O-Ring, Solvent Proof 1
13 79146-00 Seal Carrier, Rear Piston 1
14 79143-00 Bushing, Air Valve 1
15 79001-01 O-Ring, Solvent Proof 3
16 13076-13 O-Ring, Teflon 1
17 79172-00 Carrier, Rear Seal 1
18 79001-06 O-Ring, Solvent Proof 1
19 79137-00 Head, Machining 1
22 79142-00 Screw, #8-32 X .75" Long, SHCS 1
23 79171-00 Spring, Connector 1
24 79141-00 Plug, Connection 1
25 14061-09 Conductive Compressable Contact 1
B A10400-00 Seal Carrier Tool 1
Item # Item # Item # Item # Item #
79138 EVOL 79138 EVOL 79138 EVOL 79138 EVOL 79138 EVOLVER APPLICA VER APPLICA VER APPLICA VER APPLICA VER APPLICAT T T T TOR HEAD ASSEMBL OR HEAD ASSEMBL OR HEAD ASSEMBL OR HEAD ASSEMBL OR HEAD ASSEMBLY Y Y Y Y - P - P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST
(Figure 10) (Figure 10) (Figure 10) (Figure 10) (Figure 10)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
