AA-07-01
INST INST INST INST INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
1 5 1 5 1 5 1 5 1 5
Evolver 202 Robotic Atomizers - Installation
EVOL EVOL EVOL EVOL EVOLVER 202 ROBOTIC VER 202 ROBOTIC VER 202 ROBOTIC VER 202 ROBOTIC VER 202 ROBOTIC
A A A A AT T T T TOMIZER INST OMIZER INST OMIZER INST OMIZER INST OMIZER INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
This information is intended ONLY ONLY ONLY ONLY ONLY to indicate the
general installation parameters of this product
and, where applicable, its working relationship to
other ITW Ransburg system components in typi-
cal use. Each installation is unique and should be
directed by an authorized ITW Ransburg repre-
sentative or conducted from the ITW Ransburg
installation drawings provided for your particular
installation.
POWER SUPPL POWER SUPPL POWER SUPPL POWER SUPPL POWER SUPPLY Y Y Y Y
ASSEMBL ASSEMBL ASSEMBL ASSEMBL ASSEMBLY Y Y Y Y
Refer to the most current Power Supply Unit
manuals
for complete information regarding power
supply installation.
• MicroPak Control Unit (LECU5004)
(for non-FM installations)
• Stand-alone control/power supply unit
(A10406) (for FM installations)
• MicroPak Control Unit (LECU5004-31)
(for FM installations)
> The power supply MUST MUST MUST MUST MUST be located outside
the HAZARDOUS HAZARDOUS HAZARDOUS HAZARDOUS HAZARDOUS area (Reference OSHA,
NFPA-33, and your insurance company re-
quirements.)
> User should be aware of, and adhere to, all
local fire codes and ordinances.
> The user MUST MUST MUST MUST MUST provide a properly fused
disconnect between the power source and the
power supply which complies with appropriate
codes.
> Fluid supply must be grounded per NFPA-
33.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
!!!!!
