Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 74)

AA-07-01 6 9 6 9 6 9 6 9 6 9
Evolver 202 Robotic Atomizers - Parts Identification
Tubing Material Tubing Material Tubing Material Tubing Material Tubing Material Tubing Size Tubing Size Tubing Size Tubing Size Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 1/4" OD X .170" ID
B.A Bearing Air Return Yellow Nylon 1/4" OD X .170" ID
BRK Brake Air Orange Nylon 1/4" OD X .170" ID
DL1 Dump Line #1 Natural Teflon 3/8" OD X 1/4" ID
F.O Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P1.IN Paint #1 In Natural Teflon See Table K See Table K See Table K See Table K See Table K
P1T Paine #1 Trigger Green Nylon 5/32" OD X .106" ID
P1D Paint #1 Dump Orange Nylon 5/32" OD X .106" ID
P2.IN Paint #2 In Natural Teflon See Table L See Table L See Table L See Table L See Table L
P2T Paint #2 Trigger Natural Nylon 5/32" OD X .106" ID
P2D Paint #2 Dump Black Nylon 5/32" OD X .106" ID
S.A/A.A Shaping Air (Atomizer Air) Gray Nylon 3/8" OD X .275" ID
S.IN Solvent In Natural Teflon 1/4" OD X .125" ID
SL.A/F.A Seal Air (Fan Air) Blue Nylon 3/8" OD X .275" ID
ST Solvent Trigger Signal Blue Nylon 5/32" OD X .106" ID
T.A Turbine Air Green Nylon 3/8" OD X .275" ID
DL2 Dump Line #2 Natural Teflon 3/8" OD X 1/4" ID
SIGNAL SIGNAL SIGNAL SIGNAL SIGNAL IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICA IDENTIFICATION T TION T TION T TION T TION TABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH) ABLE (ENGLISH)
Abbr. Abbr. Abbr. Abbr. Abbr. Description Description Description Description Description Color Color Color Color Color
Slot in low voltage cable assembly must be aligned with slot in robot plate, as shown.
Label loose ends of fluid tubing with signal abbreviation for identification.
Install tube inserts fully into Teflon tubing before installing tubing into fitting.
Apply thread sealer 7969-10 to threads prior to assembly.
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST BULLET BULLET BULLET BULLET BULLET DEFINITION T DEFINITION T DEFINITION T DEFINITION T DEFINITION TABLE - (Figure 27) ABLE - (Figure 27) ABLE - (Figure 27) ABLE - (Figure 27) ABLE - (Figure 27)
7
6
4
3
