Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 49)

AA-07-01 4 4 4 4 4 4 4 4 4 4
Evolver 202 Robotic Atomizers - Maintenance
1 79134-00 Connecting Rod, Machined 4
2 79001-08 O-Ring, Solvent Proof 8
3 77509-00 Threaded Stud, Machined 4
4 79105-01 Bell Plate Assembly, RMA-202 1
5 79103-00 Valve Manifold Assembly, RMA-202 1
6 78449-00 Fitting,Fluid 2
7 EMF-202-04 Ferrule, Back, 1/4" Tube 2
8 EMF-203-04 Ferrule, Front, 1/4" Tube 2
9 70591-01 Nut, Fluid Fitting, 1/4" 2
10 EMF-202-05 Ferrule, Back, 1/4" Tube 2
11 EMF-203-05 Ferrule, Front, 1/4" Tube 2
12 77538-01 Tubing, 3/8" OD X .250" ID, Polyethylene 1
13 78450-00 Tube, Coiled, 1/4" OD X 1/8" ID 1
14 77508-00 Air Bolt, Machined 4
15 79001-07 O-Ring, Solvent Proof 4
16 78992-00 Ring, Break-Away, RWA-101 1
17 77524-00 Screw, Machined, Break-Away, RMA-101 6
18 79030-00 Cascade Stop Plate 1
19 79010-01 Cascade Assembly, HP-404 1
20 79001-04 O-Ring, Solvent Proof 1
21 79001-06 O-Ring, Solvent Proof 4
22 A11916 Upper Manifold, Evolver 202 1
23 SSF-2052 Set Screw, 3/8" Lg. X #10-24 1
Item # Item # Item # Item # Item #
INTERMEDIA INTERMEDIA INTERMEDIA INTERMEDIA INTERMEDIATE APPLICA TE APPLICA TE APPLICA TE APPLICA TE APPLICAT T T T TOR HOUSING - P OR HOUSING - P OR HOUSING - P OR HOUSING - P OR HOUSING - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 13) (Figure 13) (Figure 13) (Figure 13) (Figure 13)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
