Archive, Evol – Ransburg Evolver 202 Solvent A11918-XXX User Manual
Page 90
AA-07-01
Evolver 202 Robotic Atomizers - Parts Identification
8 5
8 5
8 5
8 5
8 5
Tubing Bundle
Tubing Bundle
Tubing Bundle
Tubing Bundle
Tubing Bundle
77539-01
Insert, 1/4" OD X .125" ID Tube
1
77539-02
Insert, 1/4" OD X .170" ID Tube
1
77539-03
Insert, 5/16" OD X .188" ID Tube
1
77539-04
Insert, 3/8" OD X .250" ID Tube
1
76698-01
Paint Line, 1/4" OD X .170" ID, PFA, Teflon
--
76698-02
Paint Line, 5/16" OD X .188" ID, PFA, Teflon
--
76698-03
Tubing, 1/4" OD X .125" ID, PFA, Identification
--
76698-04
Paint/Dump Line, 3/8" OD X .250" ID, PFA, Teflon
--
77536-01
Tubing, 5/32" OD X .106" ID, Black, Nylon
--
77536-03
Tubing, 8/32" OD X .106" ID, Green, Nylon
--
77536-04
Tubing, 5/32" OD X .106" ID, Blue, Nylon
--
77536-05
Tubing, 5/32" OD X .106" ID, Natural, Nylon
--
77538-01
Tubing, 3/8" OD X .2506" ID, Gray, Pe
--
SSP-6054
Male Connector, 1/4" OD X 1/8" NPT (3)
0-2
77540-06
Male Connector, 3/8" OD X 1/4" NPT
0-1
77540-04
Male Connector, 1/4" OD X 1/4" NPT
0-1
77540-05
Male Connector, 5/16" OD X .188" NPT
0-1
78449-00
Fitting
0-1
70591-01
Fitting
0-1
77544-01
Male Connector, 5/32" OD X #10-32, Threaded
8-10
A10841-03
Tubing, 6mm OD X 4mm ID, PFA, Teflon
--
A10841-02
Paint Tubing, 8mm OD X 6mm ID, PFA, Teflon
--
A10841-01
Tubing, 10mm OD X 8mm ID, PFA, Teflon
--
A10839-06
Tubing, 10mm OD X 8mm ID, Green, Nylon
--
A10839-03
Tubing, 10mm OD X 8mm ID, Silver, Nylon
--
A10893-07
Tubing, 8mm OD X 6mm ID, Blue, Nylon
--
A10840-08
Tubing, 6mm OD X 4mm ID, Yellow, Nylon
--
A10840-09
Tubing, 6mm OD X 4mm ID, Orange, Nylon
--
77536-05
Tubing, 4mm OD X .106" ID, Natural, Nylon
--
77536-01
Tubing, 4mm OD X .106" ID, Black, Nylon
--
77536-08
Tubing, 4mm OD X .106" ID, Orange, Nylon
--
A10894-01
Tubing, 4mm OD X 2.7mm ID, Orange, Nylon
--
77536-04
Tubing, 4mm OD X .106" ID, Blue, Nylon
--
77536-03
Tubing, 4mm OD X .106" ID, Green, Nylon
--
A10891-04
Fitting, 10mm OD X 1/4" NPT
0-1
A10890-03
Male Connector, 10mm OD X 1/4" NPT
0-1
A10890-02
Male Connector, 8mm OD X 1/4" NPT
0-1
A10890-01
Male Connector, 6mm OD X 1/4" NPT
0-1
A10891-03
Fitting, 8mm OD X 1/4" NPT
0-1
A10891-02
Male Connector, 6mm OD X 1/8" NPT
0-1
A10891-01
Male Connector, 4mm OD X 1/8" NPT
0-1
A10895-01
Insert, 10mm OD X 8mm ID, Tube
1
A10895-02
Insert, 8mm OD X 6mm ID, Tube
1
A10895-03
Insert, 6mm OD X 4mm ID, Tube
1
79008-XX
Low Voltage Cable
1
77062-XX
Low Voltage Cable, HP 404, Extension
1
A11353-XX
Cable Assembly, Low Voltage, Evolver MicroPak
1
A11356-XX
Low Voltage Cable, HP 404, Extension, Evolver MicroPak
1
EVOL
EVOL
EVOL
EVOL
EVOLVER 202 RECOMMENDED SP
VER 202 RECOMMENDED SP
VER 202 RECOMMENDED SP
VER 202 RECOMMENDED SP
VER 202 RECOMMENDED SPARE P
ARE P
ARE P
ARE P
ARE PAR
AR
AR
AR
ARTS (Per Applicator)
TS (Per Applicator)
TS (Per Applicator)
TS (Per Applicator)
TS (Per Applicator)
Part #
Part #
Part #
Part #
Part #
Description
Description
Description
Description
Description
Q t y .
Q t y .
Q t y .
Q t y .
Q t y .
