Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 45)

AA-07-01 4 0 4 0 4 0 4 0 4 0
Evolver 202 Robotic Atomizers - Maintenance
Figure 11: Evolver 202 60 Figure 11: Evolver 202 60 Figure 11: Evolver 202 60 Figure 11: Evolver 202 60 Figure 11: Evolver 202 60 ° ° ° ° ° Single Head Single Head Single Head Single Head Single Head Applicator Assembly Applicator Assembly Applicator Assembly Applicator Assembly Applicator Assembly
3
5
6
1
7
4
2
8
CCW TO REMOVE
1 77523-00 Upper Shroud, Machined RMA-101 1
2 77522-00 Lower Shroud, Machined RMA-101 1
3 79138-01 Spray Head Assembly, Conventional Spray 1
79138-02 Spray Head Assembly, HVLP Spray
4 79106 Tubing Bundle, RMA-202 (English) 1
A10892 Tubing Bundle, RMA-202 (Metric)
5 A11916 Manifold, Evolver 202 1
6 77524-00 Screw, Machined, RMA-101 Break-Away 2
7 78976-00 Mounting Ring, RMA-202 1
8 79179-00 Mounting Block Assembly 1
Item # Item # Item # Item # Item #
EVOL EVOL EVOL EVOL EVOLVER 202 60 VER 202 60 VER 202 60 VER 202 60 VER 202 60
°°°°° SINGLE HEAD APPLICA
SINGLE HEAD APPLICA SINGLE HEAD APPLICA SINGLE HEAD APPLICA SINGLE HEAD APPLICAT T T T TOR OR OR OR OR ASSEMBL ASSEMBL ASSEMBL ASSEMBL ASSEMBLY Y Y Y Y -----
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 1 (Figure 1 (Figure 1 (Figure 1 (Figure 11) 1) 1) 1) 1)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
ARCHIVE
