Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 70)

AA-07-01
Evolver 202 Robotic Atomizers - Parts Identification
6 5 6 5 6 5 6 5 6 5
Figure 25: A10747-00 Rear Plate Assembly (Regulator Version) Figure 25: A10747-00 Rear Plate Assembly (Regulator Version) Figure 25: A10747-00 Rear Plate Assembly (Regulator Version) Figure 25: A10747-00 Rear Plate Assembly (Regulator Version) Figure 25: A10747-00 Rear Plate Assembly (Regulator Version)
Apply thread sealer 7969-10 to threads prior to assembly.
Apply A11545-00 Petroleum jelly to o-rings.
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST BULLET BULLET BULLET BULLET BULLET DEFINITION T DEFINITION T DEFINITION T DEFINITION T DEFINITION TABLE - (Figure 25) ABLE - (Figure 25) ABLE - (Figure 25) ABLE - (Figure 25) ABLE - (Figure 25)
1
2
2
1 79027-00 Rear Mounting Plate, RMA-202 1
2 79034-00 Diaphragm, RMA-202 2
3 77541-00 Flat Washer, .089" ID X .149" OD, Stainless Steel 2
4 77543-00 Screw, #2-56 UNC X 1/4" Long, SHCS 2
5 79001-09 O-Ring, Solvent Proof 1
6 77505-00 Large Air Stud, Machined 4
7 79001-07 O-Ring, Solvent Proof 4
8 77507-00 Small Air Stud, Machined 7
9 79001-05 O-Ring, Solvent Proof 7
10 79001-06 O-Ring, Solvent Proof 9
11 79001-03 O-Ring, Solvent Proof 2
12 77506-00 Medium Air Stud, Machined 3
13 SSF-2052 Set Screw, #10-24 UNC X 3/8" Long SHCS 2
14 79001-04 O-Ring, Solvent Proof 1
15 A10744-00 Fitting, Regulator Pilot 1
Item # Item # Item # Item # Item #
A10747-00 REAR PLA A10747-00 REAR PLA A10747-00 REAR PLA A10747-00 REAR PLA A10747-00 REAR PLATE ASSEMBL TE ASSEMBL TE ASSEMBL TE ASSEMBL TE ASSEMBLY Y Y Y Y (REGULA (REGULA (REGULA (REGULA (REGULAT T T T TOR VERSION) - OR VERSION) - OR VERSION) - OR VERSION) - OR VERSION) -
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 25) (Figure 25) (Figure 25) (Figure 25) (Figure 25)
Part # Part # Part # Part # Part # Description Description Description Description Description Q t y Q t y Q t y Q t y Q t y
1
2
1
2
1
2
1
2
1
2
ARCHIVE
