Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 64)

AA-07-01
Evolver 202 Robotic Atomizers - Parts Identification
5 9 5 9 5 9 5 9 5 9
Figure 21: 79180-00 Single Head 90 Figure 21: 79180-00 Single Head 90 Figure 21: 79180-00 Single Head 90 Figure 21: 79180-00 Single Head 90 Figure 21: 79180-00 Single Head 90°
6
1
7
2
3
4
5
5
1 79189-00 Assembly, Mounting Block 90 ° Single Head 1
2 79173-00 Block, Locking 1
3 79174-00 Screw, Nylon 1/4-20 X 1-1/4" Long 1
4 79184-00 Plate, Retention 1
5 79149-00 Screw, Retaining #10-32 X .50" Long NY 2
6 79194-00 Plug, Fluid Flush 1
7 A10612 Square Cut Ring, Solvent Proof 1
Item # Item # Item # Item # Item # Part # Part # Part # Part # Part # Description Description Description Description Description
Q t y Q t y Q t y Q t y Q t y
79180-00 SINGLE HEAD 90 79180-00 SINGLE HEAD 90 79180-00 SINGLE HEAD 90 79180-00 SINGLE HEAD 90 79180-00 SINGLE HEAD 90
° ° ° ° ° - P
- P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 21) (Figure 21) (Figure 21) (Figure 21) (Figure 21)
Figure 22: 79224-00 Dual Head 90 Figure 22: 79224-00 Dual Head 90 Figure 22: 79224-00 Dual Head 90 Figure 22: 79224-00 Dual Head 90 Figure 22: 79224-00 Dual Head 90°
6
4
1
3
2
5
1 79227-00 Assembly, Mounting Block 90 ° Dual Head 1
2 79173-00 Block, Locking 2
3 79174-00 Screw, Nylon 1/4-20 X 1-1/4" Long 2
4 79184-00 Plate, Retention 2
5 79149-00 Screw, Retaining #10-32 X .50" Long NY 4
6 A-10612 Square Cut Ring, Solvent Proof 2
Item # Item # Item # Item # Item #
79224-00 DUAL 79224-00 DUAL 79224-00 DUAL 79224-00 DUAL 79224-00 DUAL HEAD 90 HEAD 90 HEAD 90 HEAD 90 HEAD 90
° ° ° ° ° - P
- P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 22) (Figure 22) (Figure 22) (Figure 22) (Figure 22)
Part # Part # Part # Part # Part # Description Description Description Description Description
Qty Qty Qty Qty Qty
ARCHIVE
