Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 37)

AA-07-01 3 2 3 2 3 2 3 2 3 2
Evolver 202 Robotic Atomizers - Maintenance
Item # Item # Item # Item # Item #
SPRA SPRA SPRA SPRA SPRAY Y Y Y Y HEAD REMOV HEAD REMOV HEAD REMOV HEAD REMOV HEAD REMOVAL AL AL AL AL / / / / / ASSEMBL ASSEMBL ASSEMBL ASSEMBL ASSEMBLY Y Y Y Y - P - P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 9b) (Figure 9b) (Figure 9b) (Figure 9b) (Figure 9b)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
1 79148-00 End Cap, Spray Head 1
2 17615-00 Spring, Compression 1
3 9334-00 Spring, Valve Return 1
4 7733-07 Jam Nut 1
5 76199-00 Rear Adjusting Nut 1
6 79151-00 Assembly, Needle Shaft 1
27 RME-38 Return Spring, Piston 1
28 EMF-7 Seal, Washer 1
29 RME-32 Seal 1
30 79001-01 O-Ring, Solvent Proof 1
31 70430-01 Electrode, High Wear 1
32 EMF-195 Nozzle, Fluid Hole 1
33 EMF-192 Locator, Air Cap 1
34 79140-02 Fluid Tip, .055" (1.4mm) Diameter 1
35 79153-65R-1 Air Cap, Pined 1
36 79154-00 Retaining Ring, Tapered 1
> Ensure that the fan and atomization air
are on and flowing prior to triggering the
fluid. Insure air before fluid adjustment is
correct. Failure to follow this sequence
will cause spits and defects on the part
being painted.
N O T E N O T E N O T E N O T E N O T E
ARCHIVE
