AA-07-01 8 6 8 6 8 6 8 6 8 6
Evolver 202 Robotic Atomizers - Parts Identification
Manifold Manifold Manifold Manifold Manifold
79010-01 Cascade Assembly, HP 404 1
77524-00 Break-Away Screw, Machined 6
EMF-203-04 Front Ferrule, 1/4" OD Tubing 2
EMF-202-04 Back Ferrule, 1/4" OD Tubing 2
EMF-203-05 Front Ferrule, 3/8" OD Tubing 2
EMF-202-05 Back Ferrule, 3/8" OD Tubing 2
79001-03 O-Ring, Solvent Proof 2
79001-04 O-Ring, Solvent Proof 2
79001-05 O-Ring, Solvent Proof 10
79001-06 O-Ring, Solvent Proof 11
79001-07 O-Ring, Solvent Proof 8
79001-08 O-Ring, Solvent Proof 10
79001-09 O-Ring, Solvent Proof 2
79034-00 Diaphragm, RMA-202 2
77541-00 Flat Washer, .089" ID X .149" OD, Stainless Steel 2
77543-00 Screw, #2-56 UNC X 1/4" Long, SHCS 2
78372-00 Set Screw, #8-32 X 1/4" Cup Point 2
76566-24C Screw, 1/4-20 X 3/4" SHCS 4-6
SSF-2052 Set Screw, #10-32 UNC X 3/8" Long, SHCS 2
78367-00 Steel Cable W/Ball and Shank 1
77517-00 Coiled Tube, 1/4" OD X .170 ID, PFA, Conductive Materials 0-1
78450-00 Coiled Tube, 1/4" OD X .125ID, PFA, Highly Conductive Materials 0-1
77531-00 Coiled Tube, 1/4" OD X .125 ID, PFA, High Resistive Materials 0-1
A11917-XX Complete Evolver 202 1
79173-00 Block, Locking 2
79142-00 Screw, #8-32 X .75 Lg. SHCS, Fiberglass 3
A10612-00 Ring, Square Cut 2-4
LSFA0027-00 Screw, Fillister HD, #10-32, Fiberglass 0-4
79206-00 Screw, Fillister HD, #10-32 X 2 1/4" Lg. 0-4
79174-00 Screw, 1/4-20 X 1 1/4" Lg., Nylon 2-4
79141-00 Connection Plug 1
A10756-00 Valve Removal Tool Accessory
A10766-00 Valve Seat Removal Tool Accessory
A10400-00 Seal Carrier Tool Accessory
76772-00 Retaining Ring Spanner Accessory
LSCH0009-00 Dielectric Grease 1
78949-00 Fluid Valve Assembly 3-5
77367-00 Valve Seat Assembly 3-5
A11214-00 Support Rod 1-2
77508-00 Air Bolt 2
77507-00 Air Stud, Small 2
77506-00 Air Stud, Medium 2
77505-00 Air Stud, Large 2
Applicator Head Applicator Head Applicator Head Applicator Head Applicator Head
9334-00 Spring, Valve Return 2
70430-01 Electrode, High Flex 4
79148-00 End Cap, Spray Head 3
EMF-7 Seal, Washer 4
EVOL EVOL EVOL EVOL EVOLVER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SP VER 202 RECOMMENDED SPARE P ARE P ARE P ARE P ARE PAR AR AR AR ARTS (Per Applicator) TS (Per Applicator) TS (Per Applicator) TS (Per Applicator) TS (Per Applicator)
(Cont.) (Cont.) (Cont.) (Cont.) (Cont.)
Part # Part # Part # Part # Part # Description Description Description Description Description Q t y . Q t y . Q t y . Q t y . Q t y .
(Continued On Next Page)
