Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 87)

AA-07-01 8 2 8 2 8 2 8 2 8 2
Evolver 202 Robotic Atomizers - Parts Identification
(Continued On Next Page) (Continued On Next Page) (Continued On Next Page) (Continued On Next Page) (Continued On Next Page)
A10407 Robot Mounting Plate 1 2 3 4 Includes:
O-Ring Kit 9 ea. - 79001-05 O-Ring
(Solvent Proof)
2 ea. - 79001-06 O-Ring
(Solvent Proof)
2 ea. - 79001-07 O-Ring
(Solvent Proof)
1 ea. - 79001-01 O-Ring
(Solvent Proof)
A10408 Manifold Assembly O-Ring 1 2 3 4 Includes:
Kit 2 ea. - 7554-10 O-Ring
(Solvent Resistant)
4 ea. - 7554-11 O-Ring
(Solvent Resistant)
4 ea. - 79001-05 O-Ring
(Solvent Proof)
2 ea. - 79001-06 O-Ring
(Solvent Proof)
1 ea. - 79001-04 O-Ring
(Solvent Proof)
1 ea. - 79209-00 O-Ring
(Solvent Resistant)
4 ea. - 7554-07 O-Ring
(Solvent Resistant)
1 ea. - 79001-09 O-Ring
(Solvent Proof)
1 ea. - 79001-14 O-Ring
(Solvent Proof)
A10409 Regulator Repair Kit 1 2 2 3 If gun is equipped with 79208-00
Regulator and Includes:
1 ea. - 79220-00 Diaphragm
1 ea. - 74161-00 Spring
1 ea. - 77354-00 Needle & Seat
1 ea. - 79001-08 O-Ring
(Solvent Proof)
A10410 Spray Head Mounting Seal 1 2 3 4 Includes:
O-Ring Kit 1 ea. - 79001-04 O-Ring
(Solvent Proof)
2 ea. - 79001-06 O-Ring
(Solvent Proof)
1 ea. - 79001-05 O-Ring
(Solvent Proof)
Part # Part # Part # Part # Part #
REP REP REP REP REPAIR KITS AIR KITS AIR KITS AIR KITS AIR KITS
Description Description Description Description Description 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8
Notes Notes Notes Notes Notes
Number of Applicators Number of Applicators Number of Applicators Number of Applicators Number of Applicators
