Ransburg Evolver 202 Solvent A11918-XXX - Manual (Page 79)

AA-07-01 7 4 7 4 7 4 7 4 7 4
Evolver 202 Robotic Atomizers - Parts Identification
3
4
4
4
3
3
1 79025-00 Robot Mounting Plate 1
2 76566-24C Screw, 1/4-20 X 3/4" Long, SHCS 6
3 SSF-2052 Set Screw, #10-32 UNC X 3/8" Long 2
4 A10891-03 Fitting, 8mm X 1/4" NPT 1
5 A10893-07 Tubing, 8mm OD X 6mm ID, Blue, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
6 A10891-04 Fitting, 10mm X 1/4" NPT 2
7 See Table Q - "N" See Table Q - "N" See Table Q - "N" See Table Q - "N" See Table Q - "N" Male Connector, 1/4" NPT 1
8 See Table Q - "P" See Table Q - "P" See Table Q - "P" See Table Q - "P" See Table Q - "P" Paint #1 Supply Tubing, PFA, Teflon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
9 See Table Q - "Q" See Table Q - "Q" See Table Q - "Q" See Table Q - "Q" See Table Q - "Q" Insert, Stainless Steel Tube 1
10 77544-01 Male Connector, 5/32" OD X #10-32 Thd. 5
11 77536-05 Tubing, 5/32" OD X .106" ID, Natural, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
12 A10891-02 Male Connector, 6mm OD X 1/8" NPT 2
13 A10840-08 Tubing, 6mm OD X 4mm ID, Yellow, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
14 A10840-09 Tubing, 6mm OD X 4mm ID, Orange, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
15 A10891-01 Male Connector, 4mm OD X 1/8" NPT 1
16 A10894-01 Tubing, 4mm OD X 2.7mm ID, Yellow, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
17 See Table Q - "V" See Table Q - "V" See Table Q - "V" See Table Q - "V" See Table Q - "V" Male Connector, 10mm OD X 1/4" NPT 1
18 See Table Q - "T" See Table Q - "T" See Table Q - "T" See Table Q - "T" See Table Q - "T" Insert, Stainless Steel Tube 1
19 See Table Q - "S" See Table Q - "S" See Table Q - "S" See Table Q - "S" See Table Q - "S" Dump Line #1, 10mm OD X 8mm ID, PFA, Teflon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
20 77536-01 Tubing, 5/32" OD X .106" ID, Black, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
21 A10839-03 Tubing, 10mm OD X 8mm ID, Silver, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
22 77536-08 Tubing, 5/32" OD X .106" ID, Orange, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
23 A10890-01 Male Connector, 6mm OD X 1/4" NPT 1
24 A10895-03 Insert, 6mm OD X 4mm ID, Tube 1
25 A10841-03 Tubing, 6mm OD X 4mm ID, PFA, Teflon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
26 77536-04 Tubing, 5/32" OD X .106" ID, Blue, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
27 77536-03 Tubing, 5/32" OD X .106" ID, Green, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
28 A10839-06 Tubing, 10mm OD X 8mm ID, Green, Nylon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
29 See Table M - "K" See Table M - "K" See Table M - "K" See Table M - "K" See Table M - "K" Low Voltage Cable 1
30 See Table P - "M" See Table P - "M" See Table P - "M" See Table P - "M" See Table P - "M" Adapter 1
31 ---- ---- ----
32 See Table N - "L" See Table N - "L" See Table N - "L" See Table N - "L" See Table N - "L" Fiber Optic Cable 1
33 See Table M - "U" See Table M - "U" See Table M - "U" See Table M - "U" See Table M - "U" Low Voltage Cable, HP-404 Extension (Not Shown) 1
34 See Table R - "Z" See Table R - "Z" See Table R - "Z" See Table R - "Z" See Table R - "Z" Dump #2 Supply Tubing, PFA, Teflon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
35 See Table R - "AB" See Table R - "AB" See Table R - "AB" See Table R - "AB" See Table R - "AB" Male Connector, 10mm OD X 1/4" NPT 1
36 See Table R - "AA" See Table R - "AA" See Table R - "AA" See Table R - "AA" See Table R - "AA" Insert, Stainless Steel Tube 1
37 See Table R - "X" See Table R - "X" See Table R - "X" See Table R - "X" See Table R - "X" Paint #2 Supply Tubing, PFA, Teflon See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H" See Table L - "H"
38 See Table R - "W" See Table R - "W" See Table R - "W" See Table R - "W" See Table R - "W" Male Connector, 1/4" NPT 1
39 See Table R - "Y" See Table R - "Y" See Table R - "Y" See Table R - "Y" See Table R - "Y" Insert, Stainless Steel Tube 1
40 77545-04 Cap, 5/32" OD Tube, Natural Identification 1
41 77545-13 Cap, 5/32" OD Tube, Orange Identification 1
42 77545-02 Cap, 5/32" OD Tube, Black Identification 1
43 77545-01 Cap, 5/32" OD Tube, Blue Identification 1
44 77545-03 Cap, 5/32" OD Tube, Green Identification 1
Item # Item # Item # Item # Item #
A10892-XXXXXXX TUBING BUNDLE ASSEMBL A10892-XXXXXXX TUBING BUNDLE ASSEMBL A10892-XXXXXXX TUBING BUNDLE ASSEMBL A10892-XXXXXXX TUBING BUNDLE ASSEMBL A10892-XXXXXXX TUBING BUNDLE ASSEMBLY Y Y Y Y (METRIC) - (METRIC) - (METRIC) - (METRIC) - (METRIC) -
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 28) (Figure 28) (Figure 28) (Figure 28) (Figure 28)
Part # Part # Part # Part # Part # Description Description Description Description Description Q t y Q t y Q t y Q t y Q t y
3
3
3
3
3
6
6
6
3
7
3
3
Apply thread sealer 7969-10 to threads prior to assembly.
Label loose ends of fluid tubing with signal abbreviation for identification.
Install tube inserts fully into Teflon tubing before installing tubing into fitting.
Apply thread sealer 7969-10 to threads prior to assembly.
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST BULLET BULLET BULLET BULLET BULLET DEFINITION T DEFINITION T DEFINITION T DEFINITION T DEFINITION TABLE - (Figure 28) ABLE - (Figure 28) ABLE - (Figure 28) ABLE - (Figure 28) ABLE - (Figure 28)
7
6
4
3
