Evolver 202 Robotic Atomizers - Introduction
6 6 6 6 6
The Evolver 202 spray applicator system con-
sists of four major components:
1. Quick-Disconnect Spray Head
2. Gun Head Mounting Block Assembly
3. Valve Manifold Assembly (Includes the High
Voltage Cascade with a Quick-Disconnect
Ring)
4. Rear Tubing Manifold Assembly (both English
and Metric)
The spray head(s) and valve manifold contain the
fluid, air, and high voltage passages. All fluid
passages contain stainless steel and/or nylon
fittings, compatible with halogenated hydrocarbon
solvents. The robot manifold incorporates stain-
less steel fluid connections.
The high voltage cascade is entirely encapsulated
with a solvent resistant epoxy. This cascade
generates voltages up to 100 kV fed by a low
voltage cable.
There are three sources for the high voltage
supply to the Evolver 202 applicators:
• MicroPak™ Control Unit (LECU5004)
(for non-FM installations)
• Stand-alone control/power supply unit
(A10406) (for FM installations)
• MicroPak TM Control Unit (LECU5004-31)
(for FM installations)
The MicroPak Power Supply Control unit provides
a low voltage signal through the robot manifold to
the spray applicator. The high voltage cascade
located within the applicator converts the low
voltage DC signal to a high voltage electrostatic
output.
