Ransburg, Rma-303 dual purge/direct charge - introduction, 30mm with and without repulsion ring – Ransburg RMA Dual Purge Direct A12300 User Manual
Page 30: Figure 2: 30mm with and without repulsion ring
RMA-303 Dual Purge/Direct Charge - Introduction
25
Figure 2: 30mm With and Without Repulsion Ring
30MM WITH AND WITHOUT
REPULSION RING
6-Inches
(152mm)
8-Inches
(203mm)
10-Inches
(254mm)
12-Inches
(305mm)
TD
19.89-Inches
(505.2mm)
20.80-Inches
(530.6mm)
21.89-Inches
(556.4mm)
22.89-Inches
(581.4mm)
X
10.68-Inches
(271.3mm)
12.41-Inches
(315.2mm)
14.14-Inches
(359.2mm)
15.88-Inches
(403.4mm)
Y
Weight: With Repulsion Ring 15.4 lbs. (7.0 Kg) total
Without Repulsion Ring 15.2 lbs. (6.9 Kg) total
Ransburg
LN-9263-08.5
5.49 [139.32]
30MM WITH AND
WITHOUT REPULSION RING
COG
COG
T.D.
.007 [.18]
14.13 [358.93]
14.91 [378.81]
"Y"
"X"
Ш5.50 [139.70]
Ш4.50 [114.30]
.67 [17.07]
16.89 [428.98]
Ш4.50 [114.17]
Ш6.06 [153.92]
1.51 [38.32]
6.33 [160.87]
13.72 [348.54]
8.16 [207.21]
60°
