Ransburg, Service kits, Rma-303 recommended spare parts (cont.) – Ransburg RMA Dual Purge Direct A12300 User Manual
Page 110: Lubricants and sealers
RMA-303 Dual Purge/Direct Charge - Parts Identification
105
Reducing Straight Connector, Push To Connect, 6mm OD Tube To 4mm OD Tube
Reducing Straight Connector, Push To Connect, 8mm OD Tube To 4mm OD Tube
Reducing Straight Connector, Push To Connect, 8mm OD Tube To 6mm OD Tube
Reducing Straight Connector, Push To Connect, 10mm OD Tube To 4mm OD Tube
Reducing Straight Connector, Push To Connect, 10mm OD To 6mm OD Tube
Reducing Straight Connector, Push To Connect, 10mm OD To 8mm OD Tube
Reducing Straight Connector, Push To Connect, 12mm OD To 8mm OD Tube
Reducing Straight Connector, Push To Connect, 12mm OD To 10mm OD Tube
SERVICE KITS
A11570-01
A11570-02
A11570-03
A11570-04
A11570-05
A11570-06
A11570-07
A11570-08
Part #
Description
Select Option Below
Shaping Air Kit A12089-09 (Dual Flex)
A12074-01
Outer Shroud
0-1
A12084-01
Shaping Air Ring
0-1
A12066-01
Turbine Retaining Ring
0-1
A12085-01
Inner Shaping Air Ring
0-1
79001-11 O-Ring
1
79001-37 O-Ring
1-2
79001-54 O-Ring
1
A12253-00
Set Screw
1
RMA-303 RECOMMENDED SPARE PARTS (Cont.)
Part #
Description
Qty
Petrolatum Jell Lubricant for all O-Rings
Thread Sealant (Blue,) Adhesive 23971
Thread Sealant (White), Adhesive 59231, Paste
LUBRICANTS AND SEALERS
A11545-00
7969-03
7969-10
Part #
Description
Ransburg
LN-9263-08.5
