Length: (See Figures 1- 4)
Diameter: (See Figures 1-4)
Approximate Weight:
Total Payload: (See Figures 1-4)
(Robot Plate & Adapter)
Turbine Type: Air Bearing Impulse
Drive
Turbine Air Supply: Variable
(See "Pressure Flow Data Charts" in this section.)
Maximum/Minimum
Turbine Speed: Continuous
30mm, 55mm, 65m
Bell Cup: 70K rpm max./20K rpm min.
Maximum Angular
Velocity for Turbine
(robot motion) 250°/sec.
Power Supply
Type: MicroPak™
Charging Method: Direct
Output Voltage: 30-100kV Variable
Output Current: 125 µA Max
Turbine Speed
Control: Eurocard Atomizer
Module
Inner/Outer Shaping
Air Control: Eurocard AirTronic
Module
Part Sprayability: Determine sprayability of
part to be coated using Test Equipment (76652)
Paint Conductivity Meter)
Bearing Air Supply: 90 psig (±10 psi)
(Nominal): (621 kPa ±69 kPa)
2.9 SCFM (82 slpm)
Shaping Air #1 (SAI): Variable
(See "Pressure Flow Data Charts" in this section)
Shaping Air #2 (SAO): Variable
(See "Pressure Flow Data Charts" in this section)
Brake Air Supply: 60-100 psig
(Nominal): (414-689 kPa)
Maximum Fluid Pressure Supply:
Paint: 200 psi (1379 kPa)
Solvent: 150 psi (1035 kPa)
Fluid Flow Rate: 25-700 cc/minute
Bell Cup Cleaning Time
(Internal/External): 2-7 sec. (Approx.)
Color Change Time: Dependent on system con-
figuration, fluid pressures, fluid viscosity, fluid line
lengths, etc.
Speed Readout: Magnetic pick-up,
unidi-rectional fiber optic
transmission
Atomizer Replacement
Time: Less than 2 minutes
Bell Cup Replacement
Time: Less than 2 minutes
Minimum Control Equipment
Requirements: (Versions listed or
higher)
MicroPak LECU5004-11 (V3.83)
Atomizer Module 76011-00 (V3.42)
I/O Module A11345-00
(V1.4) (4-20 mA)
76037-03 (V3.44)
(0-10V)
* Specifications and ratings based on testing
at sea level standard conditions.
RMA-303 Dual Purge/Direct Charge - Introduction
8
Electrical
Mechanical
SPECIFICATIONS
Mechanical (Cont.)
Ransburg
LN-9263-08.5
