DIN-MON™ SMART METER
69
62-0442—04
UCPTSendDeltaPhase_Angle
42
45
Min. time to propagate NV
SNVT_count
R/W
UCPTMinSndTReserve_A
43
45
Min. time to propagate NV
SNVT_count
R/W
UCPTMaxSndTReserve_A
43
45
Max. time to propagate NV
SNVT_count
R/W
UCPTSendDeltaReserve_A 43
45
Min.
change
in value to propagate SNVT_count_f
R/W
UCPTMinSndTReserve_B
44
46
Min. time to propagate NV
SNVT_count
R/W
UCPTMaxSndTReserve_B
44
46
Max. time to propagate NV
SNVT_count
R/W
UCPTSendDeltaReserve_B
44
46
Min. change in value to propagate SNVT_count_f
R/W
UCPTMinSndTReserve_C
45
47
Min. time to propagate NV
SNVT_count
R/W
UCPTMaxSndTReserve_C
45
47
Max. time to propagate NV
SNVT_count
R/W
UCPTSendDeltaReserve_C
45
47
Min. change in value to propagate SNVT_count_f
R/W
UCPTMinSndTExt_Input_1
46
48
Min. time to propagate NV
SNVT_count
R/W
UCPTMaxSndTExt_Input_1
46
48
Max. time to propagate NV
SNVT_count
R/W
UCPTSendDeltaExt_Input_1
46
48
Min. change in value to propagate SNVT_count_f
R/W
UCPTMinSndTExt_Input_2
47
49
Min. time to propagate NV
SNVT_count
R/W
UCPTMaxSndTExt_Input_2
47
49
Max. time to propagate NV
SNVT_count
R/W
UCPTSendDeltaExt_Input_2
47
49
Min. change in value to propagate SNVT_count_f
R/W
UCPTMinSndTDateTime
49
52
Min. time to propagate NV
SNVT_count
R/W
*
NOTE: BLK = Corresponding Function Block, VAR = Corresponding Network Variable,
SNVT = Standard Network Variable Type
NOTE
DESCRIPTION
1
The MinSendTime configuration property corresponds to the shortest time that a bound
network variable needs to wait in order to propagate an update as long as the SendDelta
value has been exceeded.
2
The MaxSendTime configuration property corresponds to the longest time that a bound
network variable needs to wait in order to propagate an update regardless of the SendDelta
value.
3
The SendDelta configuration property corresponds to the difference in value between the
current and previous value that must be exceeded in order to propagate a bound network
variable.
The MinSendTime configuration property for the nvoRTC_DateTime network variable
corresponds to the frequency at which the date and time network variable is propagated.
CONFIG. PROPERTY
BLK VAR
DESCRIPTION
UNITS
R/W
