DIN-MON™ SMART METER
62-0442—04 10
2.2 Technical Specifications
Input Voltage
Configuration
2-wire single phase, 3-wire single phase, 3-wire (Delta),
or 4-wire (WYE)
Mains Voltage Input Up To 600 VAC RMS Available
Meter Input Power
6 VA Maximum
Current Sensor
Rating
Up To 800 Amps RMS AC
Power Factor 0.5 Leading Or Lagging
Line Frequency 50-60 Hz
Meter Accuracy ANSI C12.20
Voltage Operating
Range
+/-10% Of Rated Voltage
Temperature Range -30 C To +60 C
Relative Humidity
Range
0-95% Non-condensing
Altitude 2000 Meters
Voltage Overload +25% Continuously: +100% For 20 Cycles
Pollution Degree Degree 2 In Accordance With IEC 664
Installation
(Overvoltage)
Category
Category III
Measurement
Category
Category III
Enclosure Material PPO/PS (plastic)
Display 4-Line LCD with backlight
Standards EN 61326-1:2006 IEC 61010-1:2012, 3rd Edition
Voltage Ranges 120 VAC (2-wire single phase)
277 VAC (2-wire single phase) [optional]
120/208-240 VAC (3-wire single phase)
120/208 VAC (4-wire WYE)
127/220 VAC (4-wire WYE)
240 VAC (3-wire Delta)
277/480 VAC (4-wire WYE or 3-wire Delta)
347/600 VAC (4-wire WYE only)
220/380 VAC (4-wire WYE only)
230/400 VAC (4-wire WYE only)
240/415 VAC (4-wire WYE only)
Amperage Ranges 100, 200, 400, 800 Amp
Recommended
In-line Fuse
Manufacturer Littelfuse
Mfg. Part No OKLK.500T
Rating: 500mA, 600VAC Cartridge
Fuse
