DIN-MON™ SMART METER
65
62-0442—04
NOTE
DESCRIPTION
1
To clear kWh and kVARh, set nviResetUsageCh to 1.
To clear nvoExt_Input_1, set nviResetUsageCh to 2.
To clear nvoExt_Input_2, set nviResetUsageCh to 3.
To clear nvoPeak_Dem, set nviResetUsageCh to 4.
2
To set the real time clock, set nviRTC_DateTime to the desired date and time.
3
nvoIntervalData will display the number of pulses for the selected interval period and
channel. For example: set nviIntDataTime to 6/1/2012 13:15:00 to read the number of pulses
from 13:15:00 to 13:29:59. The second status bit value will be 0 if no error has occurred.
nviIntDataPeriod will select the interval data of 15 or 5 minutes. This value will not change
the default interval data period value of 15 minutes.
nviIntDataChan will select the usage channel. For example, set nviIntDataChan to 1 to read
the interval data for nvoKWh_Del. Set nviIntDataChan to 2 to read the interval data for
nvoKVARh_Del. Set nviIntDataChan to 3 to read the interval data for nvoKWh_Rec. Set
nviIntDataChan to 4 to read the interval data for nvoKVARh_Rec.
4
nviRequest commands can disable or enable functional blocks. Any changes will be saved
even after powered down.
Set nviRequest to 0,RQ_DISABLE to disable all functional blocks. Set nviRequest to
0,RQ_ENABLE to enable all function blocks. Set nviRequest to 1,RQ_DISABLE to disable
only functional block 1.
The first value of nvoStatus is the functional block, and the 3rd bit in the bit array is 1 when
disabled.
*
NOTE: BLK = Function Block, VAR = Lon Network Variable, SNVT = Standard Network Variable Type
