DIN-MON™ SMART METER
62-0442—04 60
APPENDIX B: BACNET OBJECTS
INSTANCE
ID
BACNET
OBJECT DESCRIPTION UNITS PROPERTY R/W
1 1 Analog Input Energy delivered kWh Present Value R
2 1 Analog Input Energy received kWh Present Value R
3 1 Analog Input Reactive energy delivered kVARh Present Value R
4 1 Analog Input Reactive energy received kVARh Present Value R
5 Analog Input Real power kW Present Value R
6 Analog Input Reactive power kVAR Present Value R
7 Analog Input Apparent power kVA Present Value R
8 Analog Input Power factor % PF Present Value R
9 Analog Input Peak demand kW Present Value R
10 Analog Input Current average Amps Present Value R
11 Analog Input Voltage line-neutral Volts-N Present Value R
12 Analog Input Voltage line-line Volts-L Present Value R
13 Analog Input Frequency Hz Present Value R
14 Analog Input Phase angle Degree Present Value R
15 Analog Input Real power, phase A kW Present Value R
16 Analog Input Real power, phase B kW Present Value R
17 Analog Input Real power, phase C kW Present Value R
18 Analog Input Reactive power, phase A kVAR Present Value R
19 Analog Input Reactive power, phase B kVAR Present Value R
20 Analog Input Reactive power, phase C kVAR Present Value R
21 Analog Input Apparent power, phase A kVA Present Value R
22 Analog Input Apparent power, phase B kVA Present Value R
23 Analog Input Apparent power, phase C kVA Present Value R
24 Analog Input Power factor, phase A % PF Present Value R
25 Analog Input Power factor, phase B % PF Present Value R
26 Analog Input Power factor, phase C % PF Present Value R
27 Analog Input Current, phase A Amps Present Value R
28 Analog Input Current, phase B Amps Present Value R
29 Analog Input Current, phase C Amps Present Value R
30 Analog Input Voltage line-neutral phase A-N Volts-N Present Value R
31 Analog Input Voltage line-neutral phase B-N Volts-N Present Value R
32 Analog Input Voltage, line-neutral phase C-N Volts-N Present Value R
33 Analog Input Voltage line-line phase A-B Volts-L Present Value R
34 Analog Input Voltage line-line phase B-C Volts-L Present Value R
35 Analog Input Voltage line-line phase C-A Volts-L Present Value R
36 Analog Input Phase angle, phase A Degree Present Value R
