DIN-MON™ SMART METER
43 62-0442—04
7.2.3 Setting Device ID (BACnet)
To change the Device ID, complete the following steps:
1. Press MENU button.
2. Use UP or DOWN button until the arrow is on the
DEVICE ID line.
3. Press SELECT button.
4. Use UP or DOWN button to make changes.
5. Press SELECT button to advance to the next setting. Repeat this step until all
the Device ID settings have been updated.
6. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
7. Press UP or DOWN to select ‘Y’ or ‘N’.
8. Press SELECT button to accept the selection. This will return you to the main
menu.
9. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: EZ7 ID=[1A..1Z]..[8A..8Z]; BACnet ID=[0..4194303]
7.2.4 Setting Ethernet IP Address
To change the Ethernet IP Address, complete the following
steps:
1. Press MENU button.
2. Use UP or DOWN button until the arrow is on the IP
SETTINGS line.
3. Press SELECT button.
4. Use UP or DOWN button to make changes.
To change by digit, refer to note in Section 7.1 Navigating Menus.
5. Press SELECT button to advance to the next setting. Repeat this step until all
the IP address settings have been updated.
6. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
7. Press UP or DOWN to select ‘Y’ or ‘N’.
8. Press SELECT button to accept the selection. This will return you to the main
menu.
9. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: IP, Mask, Gateway=[000.000.000.000 – 255.255.255.255]
DEVICE ID
EZ7 1A
BACNET 2
ENABLE DHCP? N
I192.168.0.168
M255.255.255.0
G192.168.0.1
