APPENDIX C: LONWORKS PROTOCOL DATA POINTS
NETWORK VAR BLK VAR SNVT DESCRIPTION UNITS R/W
nvoWh_DelPulse 1 1 3 SNVT_count_32 Energy delivered pulse Wh Pulse R
nvoWh_RecPulse 1 2 4 SNVT_count_32 Energy received pulse Wh Pulse R
nvoVARh_RecPulse 1 3 5 SNVT_count_32 Reactive energy
delivered
VARh R
nvoVARh_DelPulse 1 4 6 SNVT_count_32 Reactive energy received VARh R
nvoKWh_Del 1 5 7 SNVT_count_inc_f Energy delivered kWh R
nvoKWh_Rec 1 6 8 SNVT_count_inc_f Energy received kWh R
nvoKVARh_Del 1 7 9 SNVT_count_inc_f Reactive energy
delivered
kVARh R
nvoKVARh_Rec 1 8 10 SNVT_count_inc_f Reactive energy received kVARh R
nvoReal_Pwr 9 11 SNVT_count_inc_f Real power kW R
nvoReact_Pwr 10 12 SNVT_count_inc_f Reactive power kVAR R
nvoAppar_Pwr 11 13 SNVT_count_inc_f Apparent power kVA R
nvoPwr_Fact 12 14 SNVT_pwr_fact_f Power factor % PF R
nvoPeak_Dem 1 13 15 SNVT_count_inc_f Peak demand kW R
nvoCurrent_Avg 14 16 SNVT_amp_f Current average Amps R
nvoVolt_LN 15 17 SNVT_volt_f Voltage line-neutral Volts-N R
nvoVolt_LL 16 18 SNVT_volt_f Voltage line-line Volts-L R
nvoFrequency 17 19 SNVT_freq_f Freq. Hz R
nvoPhase_Angle 18 20 SNVT_count_inc_f Phase angle Degree R
nvoReal_Pwr_PhA 19 21 SNVT_count_inc_f Real power, phase A kW R
nvoReal_Pwr_PhB 20 22 SNVT_count_inc_f Real power, phase B kW R
nvoReal_Pwr_PhC 21 23 SNVT_count_inc_f Real power, phase C kW R
nvoReact_Pwr_PhA 22 24 SNVT_count_inc_f Reactive power, phase A kVAR R
nvoReact_Pwr_PhB 23 25 SNVT_count_inc_f Reactive power, phase B kVAR R
nvoReact_Pwr_PhC 24 26 SNVT_count_inc_f Reactive power, phase C kVAR R
nvoAppar_Pwr_PhA 25 27 SNVT_count_inc_f Apparent power, phase kVA R
nvoAppar_Pwr_PhB 26 28 SNVT_count_inc_f Apparent power, phase kVA R
nvoAppar_Pwr_PhC 27 29 SNVT_count_inc_f Apparent power, phase kVA R
nvoPwr_Fact_PhA 28 30 SNVT_pwr_fact_f Power factor, Ph. A % PF R
nvoPwr_Fact_PhB 29 31 SNVT_pwr_fact_f Power factor, Ph. B % PF R
nvoPwr_Fact_PhC 30 32 SNVT_pwr_fact_f Power factor, Ph. C % PF R
nvoCurrent_PhA 31 33 SNVT_amp_f Current, phase A Amps R
nvoCurrent_PhB 32 34 SNVT_amp_f Current, phase B Amps R
nvoCurrent_PhC 33 35 SNVT_amp_f Current, phase C Amps R
nvoVolt_LN_PhA_N 34 36 SNVT_volt_f Voltage line-neutral
phase A-N
Volts-N R
nvoVolt_LN_PhB_N 35 37 SNVT_volt_f Voltage line-neutral
phase B-N
Volts-N R
nvoVolt_LN_PhC_N 36 38 SNVT_volt_f Voltage, line-neutral
phase C-N
Volts-N R
* NOTE: BLK = Function Block, VAR = Lon Network Variable, SNVT = Standard Network Variable Type
