DIN-MON™ SMART METER
62-0442—04 50
8.2 Reading the Meter Display
The Din-Mon TM meter features seven different screens showing monitoring data. Each
screen is displayed for 5 second intervals, before scrolling onto the next screen.
You can “lock” the scrolling display on any one of the seven screens. This will be
explained in detail on following pages. Explanations of these displays are as follows:
NOTE: Not all items will be shown on 1-phase or 2-phase models.
Screen Description Display
1 Total Kilowatt-Hours (kWh) Consumed
(Delivered)
2 Peak Demand (kW)
with Date and Time Stamp
3 Present Load (kW)
with Present Date and Time
4 Current (Amps) Per Phase
5 Voltage (Volts)
Phase to Neutral (for WYE service)
6 Voltage (Volts) Phase to Phase
7 Power Factor (PF) Per Phase
TOTAL:
123 KWH
PEAK 25.5 KW
DATE 05/15
TIME 11:45
LOAD 24.0 KW
DATE 06/14/11
TIME 08:46:58
PH-A 119.8 V
PH-B 120.2 V
PH-C 119.5 V
PH-A 12.3 AMP
PH-B 10.2 AMP
PH-C 14.7 AMP
PH-AB 208.0 V
PH-BC 208.2 V
PH-CA 207.0 V
PH-A 97.4 % PF
PH-B 98.2 % PF
PH-C 98.6 % PF
