DIN-MON™ SMART METER
62-0442—04
42
7.2.1 Setting Date and Time
To change the date and time, complete the following steps:
1. Press MENU button.
2. Press SELECT button. The 2-digit month will be
blinking.
3. Use UP or DOWN button to make changes.
4. Press SELECT button to advance to the next setting.
Repeat this step until all the date and time settings have been updated.
5. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
6. Press UP or DOWN to select ‘Y’ or ‘N’.
7. Press SELECT button to accept the selection. This will return you to the main
menu.
8. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: MM-DD-YYYY, MM=[1..12], DD=[1..31], YYYY=[2000..2???];
HH:MM:SS, HH=[0..24], MM=[0..59], SS=[0..59]
7.2.2 Setting Device ID (Modbus)
To change the Device ID, complete the following steps:
1. Press MENU button.
2. Use UP or DOWN button until the arrow is on the
DEVICE ID line.
3. Press SELECT button.
4. Use UP or DOWN button to make changes.
5. Press SELECT button to advance to the next setting. Repeat this step until all
the Device ID settings have been updated.
6. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
7. Press UP or DOWN to select ‘Y’ or ‘N’.
8. Press SELECT button to accept the selection. This will return you to the main
menu.
9. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: EZ7 ID=[1A..1Z]..[8A..8Z]; Modbus ID=[1..247]
DATE
02-14-2013
TIME
13:45-59
DEVICE ID
EZ7
1A
MODBUS
2
