Page 46

DIN-MON™ SMART METER
62-0442—04
46
7.2.9 Setting CT Selection
To change the CT Selection, complete the following steps:
1. Press MENU button.
2. Use UP or DOWN button until the arrow is on the CT
SELECTION line.
3. Press SELECT button.
4. Use UP or DOWN button to make changes.
5. Press SELECT button to advance to the next setting. Repeat this step until all
the CT selection settings have been updated.
6. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
7. Press UP or DOWN to select ‘Y’ or ‘N’.
8. Press SELECT button to accept the selection. This will return you to the main
menu.
9. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: CT TYPE=[Split or Solid]; CT SIZE=[50, 100, 200, 400, 800] Amps
7.2.10 Setting Access Protection
To change the Access Protection, complete the following
steps:
1. Press MENU button.
2. Use UP or DOWN button until the arrow is on the
ACCESS PROTECT line.
3. Press SELECT button.
4. Use UP or DOWN button to make changes.
5. Press SELECT button to advance to the next setting. Repeat this step until all
the Access Protection settings have been updated.
6. Press MENU to complete the changes. If changes were made, you’ll be asked to
save changes.
7. Press UP or DOWN to select ‘Y’ or ‘N’.
8. Press SELECT button to accept the selection. This will return you to the main
menu.
9. Select EXIT to get out of programming mode and return to normal display mode.
FIELD RANGE: REMOTE=[Y or N]; LCD=[Y or N]
CT TYPE
SPLIT
CT SIZE
200
ACCESS PROTECT
REMOTE
Y
LCD
Y
