6 Image capture
Displaying a camera image
A camera image display appears in a SPARKlab.
3. Touch the
Live Image button at the center of the display.
A live camera view appears in the display.
From within a SPARKlab
1. Touch the
New Page button.
The build a new page screen opens.
2. Touch an
Image measurement.
When selected,
Image is highlighted in orange.
3. Touch the large or small
Image button.
An image display is added to the preview.
4. Touch
OK.
A new page containing an image display is added to the SPARKlab.
5. Touch the
Live Image button at the center of the display.
