9 Building SPARKlab pages
Removing or replacing an image in a image box
3. Touch OK.
The new page containing the empty image box appears.
4. On a computer, save an image file to a USB flash drive (or other USB storage device).
5. Connect the flash drive to USB port of the SPARK.
6. On the SPARKlab page, touch the image box.
The image palette appears.
7. Touch the Load button.
The Open window appears.
8. Touch an image file to select it.
9. Touch Open.
The image from the selected file appears in the image box.
10. Optionally, touch the image to hide the image palette.
11. Optionally, remove the USB flash drive.
Removing or replacing an image in a image box
Touch the image to open the image palette.
Do one of the following:
l
Touch the Remove button to delete the image.
l
Touch the Load button to load a new image file.
Locking an image
Once an image is locked it cannot be changed or removed. However, the SPARKlab page that
contains the locked image can be deleted.
012-10616E
95
