Adding annotations to bars – PASCO SPARK Science Learning System Ver. 1.4.0 User's Guide User Manual
Page 45
5 Data display
Displaying data in a bar graph
Showing numeric values on bars
Adding annotations to bars
If there is more than one data run on the graph, first select the run that the annotation will be
attached to:
1. Touch the graph legend.
The legend enlarges.
2. In the legend, touch the symbol of the run(s) that you want to annotate.
3. Touch the
Bar Graph Tools button to open the tool palette.
4. Touch the
Annotation button.
5. Touch a bar.
The Enter Note screen appears.
012-10616E
36
