2 Starting an experiment
Monitoring live data
You can use up to two PASPORT sensors plus a temperature probe and a voltage probe.
Complete one or more of the following tasks to connect sensors to the SPARK.
l
Connecting PASPORT sensors
l
Connecting a temperature probe
l
Connecting a voltage probe
Connecting PASPORT sensors
1. Plug a PASPORT sensor into one of the PASPORT ports on the top of the SPARK SLS.
2. Optionally, plug a second PASPORT sensor into the other PASPORT port.
Connecting a temperature probe
Plug the included fast-response temperature probe (or other type of temperature probe) into
the temperature port on the top of the SPARK SLS.
Connecting a voltage probe
Plug the included voltage probe into the voltage port on the top of the SPARK SLS.
Monitoring live data
Live data from all connected sensors are displayed whenever the Home screen is open.
The Home screen is the first screen that appears when SPARK SLS starts.
If the Home screen is not visible, touch the Home button to return to the Home screen.
012-10616E 3
