2 Starting an experiment
Turning on the SPARK SLS
2
Starting an experiment
1.
2.
Connecting sensors to the SPARK SLS
3.
4.
Moving on from the Home screen
Turning on the SPARK SLS
1. If the battery is not charged, connect the included AC adapter to a wall outlet and to the
AC adapter port on the bottom of the SPARK.
2. Press and hold the power button.
The SPARK turns on, boots up, and displays the Home screen.
1. AC adapter port. 2. Power button.
Connecting sensors to the SPARK SLS
1. PASPORT ports. 2. Temperature port. 3. Voltage port.
012-10616E
2
