Micromod MOD: 30ML Display Script Guide User Manual
Page 27
MOD 30ML Display Guide
Display Basics
2 -21
2.4.4 Exercise: Creating an Indicating Totalizer using Display Block
Menus
Using only the Inputs menu, the Formats menu, and the entries on the main screen it is
possible to construct many useful displays without creating either State Tables or Scripts.
This exercise shows how to create an Indicating Totalizer display for use with a Totalizer
block. The resulting display will look similar to the diagram shown in Figure 14.
Figure 2 .15.
Totalizer Display for
Exercise …
Exercise:
Creating an
Indicating Totalizer
Action
Comment
1. Place a Totalizer block in the strategy.
2. Configure the Totalizer block. Give a tag
name for the totalizer block.
See the next figure.
