MOD 30ML Display Guide
Display Basics
2 -19
The Display Format is selected using the pull-down menu. Table 2-1 shows the format
types and how the data appears for each. For example, most analog variables such as
Process and Setpoint are displayed as a Float, with one to six places to the right of the
decimal point.
Table 2 .1
Display Format
Menu
Display
Format Used For Appears As
Float0 Continuous (analog) variables X
Float1 Continuous (analog) variables X.X
Float2 Continuous (analog) variables X.XX
Float3 Continuous (analog) variables X.XXX
Float4 Continuous (analog) variables X.XXXX
Float5 Continuous (analog) variables X.XXXXX
Float6 Continuous (analog) variables X.XXXXXX
Integer1 Discrete, Short State, Long State Integer
Integer2 Count Integer
Integer4 Millisecond Time Integer
Time1 Time HH:MM:SS
Time2 Time M:SS.SSS
Time3 Time HHHH:MM
Time4 Time MM:SS.SSS
State Discrete, Short State, Long State, Count As defined in
State Table
ASCII ASCII ASCII
Hex Hex Hex
Date Date mm/dd/yy or
dd/mm/yy
Bar Discrete, Short State, Long State, Count,
Millisecond Time, Floating Point Bargraph
Deviation Discrete, Short State, Long State, Count,
Millisecond Time, Floating Point Bargraph
High Limits and Low Limits are used to for continuous variables that have limits for
operator entry, such as setpoint and output. If there is no operator entry, limits need not
be entered. When the format is a bar or deviation the high and low limits are used to
define the upper and lower range values for the bar.
If an operator will enter or change the value from the front panel using the up/down
arrows, an Entry Method must be selected. When set to Entry Required, the operator
must press the flashing ENT key before the changed value is entered. When set to
Immediate, the new value is entered as soon as the Display Block is executed (on the
next scan).
