Table C-2. Database
Data-
point
Title
Symbol
Default
Section
4
Table
Module
H033
Totalizer 1 Actual Total (Display Only)
TO1
0
4-8
Totalizer
H034
Totalizer 2 Actual Total (Display Only)
TO2
0
4-8
Totalizer
H035
Totalizer 3 Actual Total (Display Only)
TO3
0
4-8
Totalizer
H048
Totalizer 0 Rollover Value
TMM0
1000000
4-8
Totalizer
H049
Totalizer 1 Rollover Value
TMM1
1000000
4-8
Totalizer
H050
Totalizer 2 Rollover Value
TMM2
1000000
4-8
Totalizer
H051
Totalizer 3 Rollover Value
TMM3
1000000
4-8
Totalizer
L000
CCI0 Contact Input
CCI0
0
4-5
CCI
L001
CCI1 Contact Input
CCI1
0
4-5
CCI
L024
CCO0 Contact Output (Display Only)
CCO0
0
4-6
CCO
L025
CCO1 Contact Output (Display Only)
CCO1
0
4-6
CCO
L110
ALRM0 Alarm A (ANI0) (Display Only)
PA10
0
4-7
Alarm
L111
ALRM0 Alarm B (ANI0) (Display Only)
PA20
0
4-7
Alarm
L134
ALRM1 Alarm A (ANI1) (Display Only)
PA11
0
4-7
Alarm
L135
ALRM1 Alarm B (ANI1) (Display Only)
PA21
0
4-7
Alarm
L158
ALRM2 Alarm A (ANI2) (Display Only)
PA12
0
4-7
Alarm
L159
ALRM2 Alarm B (ANI2) (Display Only)
PA22
0
4-7
Alarm
L182
ALRM3 Alarm A (ANI3) (Display Only)
PA13
0
4-7
Alarm
L183
ALRM3 Alarm B (ANI3) (Display Only)
PA23
0
4-7
Alarm
L224
Totalizer 0 Output Pulse
TMP0
0
4-8
Totalizer
L225
Totalizer 1 Output Pulse
TMP1
0
4-8
Totalizer
L226
Totalizer 2 Output Pulse
TMP2
0
4-8
Totalizer
L227
Totalizer 3 Output Pulse
TMP3
0
4-8
Totalizer
L232
Totalizer 0 Reset
TMR0
0
4-8
Totalizer
L233
Totalizer 1 Reset
TMR1
0
4-8
Totalizer
L234
Totalizer 2 Reset
TMR2
0
4-8
Totalizer
L235
Totalizer 3 Reset
TMR3
0
4-8
Totalizer
L256
No Parity
CP
0
4-9
COMM
L257
Datalink Disable
DLD
0
4-9
COMM
L258
No Byte Stuffing
CB
0
4-9
COMM
L264
CCI0 Contact Input Invert
IINV0
0
4-5
CCI
L265
CCI1 Contact Input Invert
IINV1
0
4-5
CCI
L288
CCO0 Contact Output Invert
OINV0
0
4-6
CCO
L289
CCO1 Contact Output Invert
OINV1
0
4-6
CCO
L352
CCI0 Display Mode
SMA
0
4-5
CCI
L353
CCI1 Display Mode
SMB
0
4-5
CCI
L368
CCI0 Alarm Enable
SAA
0
4-5
CCI
L369
CCI1 Alarm Enable
SAB
0
4-5
CCI
L416
ANI0 0-5 V Input
NOBIAS0
0
4-3
ANI
L417
ANI1 0-5 V Input
NOBIAS1
0
4-3
ANI
L418
ANI2 0-5 V Input
NOBIAS2
0
4-3
ANI
L419
ANI3 0-5 V Input
NOBIAS3
0
4-3
ANI
