Micromod Micro-DCI: 53IT5100A Indicator/Totalizer - Manual (Page 51)

Table 4-7. Alarm Module
Purpose: The primary purpose of this module is to set the instrument’s Alarm Index mode, Alarm
Limits 1 & 2, and Alarm Dead Band.
Title Symbol CON Data-
point
De-
fault
Attribute
Alarm
Index AIX0
AIX1
AIX2
AIX3 ALRM0
ALRM1
ALRM2
ALRM3 B335
B340
B345
B350 1
1
1
1 This parameter defines the Alarm Active (PA1 &
PA2) interpretation of the two Alarm Limits (PL1 &
PL2). It is entered into the datapoint as an index
value (0-5 ) as follows (n = 0-3 and correlates
with ALRM0 through ALRM3):
0 PA1n: high when PV> PL1n
PA2n: low when PV< PL2n
1 - None
2 PA1n: high when PV> PL1n
PA2n: not affected
3 PA1n: not affected
PA2n: low when PV< PL1n
4 PA1n: high when PV> PL1n
PA2n: hi-hi when PV> PL2n
5 PA1n: low when PV< PL1n
PA2n: lo-lo when PV< PL2n
Examples are provided as follows:
Alarm Examples:
B335 PV PL1
(C103)
PL2
(C104)
Alarm Notes
0 >60 60 high Alarm Llimit 1 is set for 60: PV > 60 = high Alarm.
0 <40 40 low Alarm Limit 2 is set for 40: PV < 40 = low Alarm.
2 >60 60 high Alarm Limit 1 is set for 60: PV > 60 = high Alarm.
2 <40 40 N/A Alarm Limit 2 is set for 40: PV < 40 = no alarm.
3 >60 60 N/A Alarm Limit 1 is set for 60: PV > 60 = no alarm.
3 <40 40 low Alarm Limit 2 is set for 40: PV < 40 = low Alarm.
4 >60 60 high Alarm Limit 1 is set for 60: PV > 60 = high Alarm.
4 >70 70 hi-hi Alarm Limit 2 is set for 70: PV > 70 = hi-hi Alarm.
5 <40 40 low Alarm Limit 1 is set for 40: PV < 40 = low Alarm.
5 <30 30 lo-lo Alarm Limit 2 is set for 30: PV < 30 = lo-lo Alarm.
53IT5100 Indicator/Totalizer
4-8
