Table 4-5. Contact Input Module (CCI)
Purpose: This module allows the action of the CCIs to be reversed (normally a closed contact =
1, but can be changed to = 0).
Title Symbol CCI Data-
point
De-
fault
Attribute
Contact
Input
(Display
Only) CCI0
CCI1 CCI0
CCI1 L000
L001 0
0 When open, a 4 - 24 V dc input signal = 0
when IINV = 0.
When open, a 4 - 24 V dc input signal = 1
when IINV = 1.
When closed, a < 1 V dc input signal = 1
when IINV = 0.
When closed, a < 1 V dc input signal = 0
when IINV = 1.
Contact
Input
Invert IINV0
IINV1 CCI0
CCI1 L264
L265 0
0 As shown above, it reverses the action of the
CCI datapoint.
Display
Message CCI0
CCI1 A055
A056 ALARM A
ALARM B The messages for CCI0 and CCI1,
respectively, on the Alarm Summary display.
Tag
Name CITAG0
CITAG1 CCI0
CCI1 A262
A263 CCI-0
CCI-1 It is an assignable 10 character name for the
contact control input.
Display
Mode SMA
SMB CCI0
CCI1 L352
L353 0
0 Display Mode, Alarm Enable, and Contact
Input interact to alter the two five character
segments of the Display Messages (A055 and
A056) as shown in the table that follows:
Alarm
Enable SAA
SAB CCI0
CCI1 L368
L369 0
0
Alarm Enable = 0 Alarm Enable = 1
Contact Input = 0 1 0 1
Display Mode
= 0
10 character
message. 10 character
message in
reverse video. 10 character
message. 10 character message
blinking in reverse video
with Alarm Banner also
blinking. (After pressing
Mode push button, 10
character message
appears in reverse video.)
Display Mode
= 1
First half (5
characters) of 10
character
message
sequence. Second half (5
characters) of
10 character
message
sequence. First half (5
characters) of
10 character
message
sequence. Second half (5
characters) of 10
character message
blinking with Alarm
Banner blinking. (After
pressing Mode push
button, 5 character
message remains, but
stops blinking.)
No message blinking and no Alarm Banner
blinking.
No message blinking and no Alarm Banner
blinking.
