Micromod Micro-DCI: 53IT5100A Indicator/Totalizer - Manual (Page 53)

Table 4-8. Totalizer Module
Purpose: The totalizers provide a running total of each analog input (ANI0-3). This module is
used to set input scaling factors, rollover and dropout values, and to define display tags for each
totalizer.
Title Symbol TM Data-
point
De-
fault
Attribute
Tag
Name TMTAG0
TMTAG1
TMTAG2
TMTAG3 TM0
TM1
TM2
TM3 A092
A094
A096
A098 TOTAL-0
TOTAL-1
TOTAL-2
TOTAL-3 These are assignable 10 character names that
appear on the totalizer display.
Engineer-
ing
Units TMEU0
TMEU1
TMEU2
TMEU3 TM0
TM1
TM2
TM3 A093
A095
A097
A099 UNITS
UNITS
UNITS
UNITS These are assignable 10 character names that
appear on the totalizer display as the units of
measure.
Scale
Factor TMF0
TMF1
TMF2
TMF3 TM0
TM1
TM2
TM3 C318
C320
C322
C324 16666
16666
16666
16666 The value of the input is multiplied by this
parameter prior to being summed to the running
total. The parameter is used for both scaling and
time interval integration. For example, if ANI0 is
in M gallons/day, in order to totalize in K gallons
the scale factor (SF) would be:
SF = [Units Conversion] X [Time Base
Conversion]
SF = [1000 K gal / M gal] X [(1 day/24 hrs) X (1
hr/60 mins) X (1 min/60 sec) X (1 sec/sample)] =
1000/86400 = 0.01157
Note: The time between totalizer updates is one
second.
The default value of 16666 uses the scale factor
for time interval integration. Due to the internal
timing of the instrument, a scale factor of 16666
will cause the rollover total to occur once every
minute.
Rollover
Value TMM0
TMM1
TMM2
TMM3 TM0
TM1
TM2
TM3 H048
H049
H050
H051 1000000
1000000
1000000
1000000 It specifies the maximum value of the totalizer.
When the total reaches this value it is reset to
0.0; however totalizing continues. This value
must be a positive number.
Dropout
Value TMD0
TMD1
TMD2
TMD3 TM0
TM1
TM2
TM3 C319
C321
C323
C325 0
0
0
0 When the input value is less than this value, no
change in the total occurs.
Reset TMR0
TMR1
TMR2
TMR3 TM0
TM1
TM2
TM3 L232
L233
L234
L235 0
0
0
0 This parameter acts like a momentary switch.
When this parameter is set to 1 the total is forced
to 0.0 and then this parameter is reset to 0.
53IT5100 Indicator/Totalizer
4-10
