Table 4-7. Alarm Module
Purpose: The primary purpose of this module is to set the instrument’s Alarm Index mode, Alarm
Limits 1 & 2, and Alarm Dead Band.
Title Symbol CON Data-
point
De-
fault
Attribute
Alarm A
(Display
Only) PA10
PA11
PA12
PA13 ALRM0
ALRM1
ALRM2
ALRM3 L110
L134
L158
L182 0
0
0
0 When active, it indicates one of the four PA1
conditions (PA10-PA13) specified in its respective
Alarm Index (AIX0-AIX3) has an alarm indication
as determined by the index value (0-5) that was
entered for the Alarm Index.
Alarm B
(Display
Only) PA20
PA21
PA22
PA23 ALRM0
ALRM1
ALRM2
ALRM3 L111
L135
L159
L183 0
0
0
0 When active, it indicates one of the four PA2
conditions (PA20-PA23) specified in its respective
Alarm Index (AIX0-AIX3) has an alarm indication
as determined by the index value (0-5) that was
entered for the Alarm Index.
Alarm
Limit 1 PL10
PL11
PL12
PL13 ALRM0
ALRM1
ALRM2
ALRM3 C103
C139
C175
C211 100
100
100
100 These parameters are the points in
engineering units at which the alarms are
triggered.
Alarm
Limit 2 PL20
PL21
PL22
PL22 ALRM0
ALRM1
ALRM2
ALRM3 C104
C140
C176
C212 0
0
0
0
Alarm
Dead
Band ADB0
ADB1
ADB2
ADB3 ALRM0
ALRM1
ALRM2
ALRM3 C105
C141
C177
C213 2
2
2
2 This parameter sets the activation/deactivation
gap for the alarm. This value in engineering units
defines an area of hysteresis at the alarm point.
