Table 1-1. specifications – Micromod Micro-DCI: 53IT5100A Indicator/Totalizer User Manual
Page 18
Table 1-1. Specifications
Item
Specification(s)
Physical Characteristics
Material of Construction:
Case
Circuit Boards
Bezel
Dimensions
Flush Panel Mounting
Electrical Connections
Weight
Front Panel Display
Front Panel Push Buttons
Steel, black enamel
Glass epoxy
ULTEM 1000
(Polyethermide Resin)
Flammability-UL94 5V
2.844W x 5.656H x 12.906L (inches)
73W x 144H x 329L (mm)
0.125 inch - 1 inch thickness
(3.2 mm - 25.4 mm)
Screw type terminal block at rear of casework
5 lbs (2.3 kg)
96 x 48 dot addressable
10 membrane type switches
Section 1. Introduction
1-13
