2. If F2 is selected, the following menu appears:
F2-DATABASE
F3-PROGRAM (not applicable)
Based on which selection from this menu is made the following operations can occur:
•
F2- DATABASE: This operation copies the entire database, all B, L, C, H, and A, data-
point values, in the instrument to the storage cartridge. Transfer takes approximately 12
seconds.
•
F3- PROGRAM: This operation is not applicable for this instrument.
When the transfer begins a message is displayed indicating the transfer has started. An-
other message appears when the transfer is completed. If the transfer fails, an error mes-
sage is displayed instead of the transfer completed message. If an error does occur,
resolve the cause and re-initiate the transfer. A transfer error should not be ignored, as a
partial transfer may cause the HHC cartridge to contain corrupted data. The HHC returns
to the command entry mode if the transfer is successful or if it is halted with an error mes-
sage.
3.5.1.6 SAMPLE HAND HELD CONFIGURER COMMANDS
The following table provides a sample of typical Hand Held Configurer Display (D ), Put (P ), and
Memory Transfer (T ) commands.
Key Entries Displayed Data Result
D B101 D B101 XXX Displays contents of B101.
D N D B102 XXX Displays contents of B102.
D D B102 XXX B102 contents still displayed.
P C256 200 P C256 200 Alters contents of C256 to 200
P 150 P C256 150 Alters contents of C256 to 150.
P N 200 P C257 200 Alters contents of C257 to 200.
T MEMORY TRANSFER
F1 - TO CONTROLLER
F2 - FROM CONTROLLER
✦
✦
✦
TRANSFER FINISHED
Displays memory transfer query
to either send database
information (or analog
constants) to the instrument, or
receive database information
(or analog constants) from the
instrument.
Note: XXX = Displayed characters from addressed datapoint.
