Micromod Micro-DCI: 53IT5100A Indicator/Totalizer - Manual (Page 17)

Table 1-1. Specifications
Item Specification(s)
Environmental Characteristics (Cont):
Transient Immunity (all circuits)
EMI Susceptibility
Enclosure Classification/Environment
Shock
Vibration
Drop and Topple
Safety Classification
ANSI C37.90a - 1974/IEEE Std 472- 974:
Ring Wave: 1.5 MHz, 3 kV, 60 pulses/s for 2.0 s
SAMA PMC 33.1-1978: Class 3-abc: no effect
at 30 V/m, at 27, 146, and 446 MHz
Panel Mounted Equipment: No enclosure
rating. Designed to be installed in a user
provided panel or enclosure.
Rated for installation in a Pollution Degree 2
location per U.L. 508-1989/Controlled
Environment per CSA C22.2 No. 142-M1987.
An indoor, temperature controlled location
(Control Room or Shop Floor) where normally,
only non-conductive pollution occurs; however,
temporary conductivity caused by condensation
may be expected.
Location in environments more severe than
those stated requires supplementary protection.
0.5 g
SAMA PMC 31.1-1978; point-to-point constant
displacement 0.05 in. (1.27 mm), 5 - 14 Hz: 0.5
g, 14 - 200 Hz.
SAMA PMC 31.1-1978; Tilt 30 degrees from
horizontal and fall freely to a hard surface, all
sides, front and back.
General Purpose: Complies with ANSI/ISA
S82.01-1988, Safety Standard for Electrical and
Electronic Test Measuring, Controlling and
Related Equipment; General Requirements and
S82.03-1988 Safety Standard for Electrical and
Electronic Test, Measuring, Controlling and
Related Equipment; Electrical and Electronic
Process Measurement and Control Equipment.
FM Approved: Nonincendive for Class 1,
Division 2, Groups A, B, C, & D, Temperature
Code T3C 160
°
C.
53IT5100 Indicator/Totalizer
1-12
