Micromod Micro-DCI: 53IT5100A Indicator/Totalizer - Manual (Page 50)

Table 4-6. Contact Output Module (CCO)
Purpose: This module allows the action of the CCOs to be reversed (normally a closed contact =
1, but can be changed to = 0) and is used to select the signal or condition that activates the CCO.
Title Symbol CCO Data-
point
De-
fault
Attribute
Contact
Output
(Display
Only) CCO0
CCO1 CCO0
CCO1 L024
L025 0
0 If CCO = 0 and OINV = 0, then it is open.
If CCO = 0 and OINV = 1, then it is closed.
If CCO = 1 and OINV = 0, then it is closed.
If CCO = 1 and OINV = 1, then it is open.
Contact
Output
Invert OINV0
OINV1 CCO0
CCO1 L288
L289 0
0 As shown above, it reverses the action of the
CCO datapoint.
Control
Contact
Output
Source CCO0
CCO1 B101
B102 110
134 This parameter selects the signal or condition
that activates the CCO. The routing index values
are as follows:
110 Channel 0 Alarm A (PA10).
111 Channel 0 Alarm B (PA20).
134 Channel 1 Alarm A (PA11).
135 Channel 1 Alarm B (PA21).
158 Channel 2 Alarm A (PA12).
159 Channel 2 Alarm B (PA22).
182 Channel 3 Alarm A (PA13).
183 Channel 3 Alarm B (PA23).
0 Contact Input 0 (CCI0).
1 Contact Input 1 (CCI1).
224 Totalizer 0 Rollover Pulse (TMP0).
225 Totalizer 1 Rollover Pulse (TMP1).
226 Totalizer 2 Rollover Pulse (TMP2).
227 Totalizer 3 Rollover Pulse (TMP3).
65 Horn - latches the OR function of all
alarms (8 process alarm bits and 2 contact
input alarms).
99 Non-latched OR function of all alarms (8
process alarm bits and 2 contact input
alarms). It is cleared when the last alarm
goes away.
Tag
Name COTAG0
COTAG1 CCO0
CCO1 A280
A281 CCO-0
CCO-1 It is an assignable 10 character name for the
contact control output.
Section 4. Configuration Parameters
4-7
