3.5.1.2 DISPLAYING A DATABASE PARAMETER
To DISPLAY a database parameter, press D and enter the parameter ID, then press ENTER. The
current value of the parameter is displayed. The parameter ID is the data type identifier (B, L, C, H,
F, and A) and point number as described in Table 4-1 of Section 4.
For example, to display the value of datapoint B12, press:
D B12
The value presently assigned to B12 is displayed.
Values displayed with the D command are formatted as follows:
Data Type
Data Format
B
Are three digit characters 000-255.
L
Is a one digit character 0 or 1.
C & H
Are ten digit characters including
digits, decimal point and sign (when
negative). Zero = 0.0.
A & Q
Are ten characters or less.
Pressing ENTER after pressing D automatically recalls the last data base parameter ID used.
Pressing N after pressing D causes the next parameter of the same data type to be displayed. (The
NEXT command N only works with index numbers below 256.)
3.5.1.3 ALTERING A DATABASE PARAMETER
To modify a value or enter a new value press P and the parameter ID followed by ENTER. Then
press the keys corresponding to the value to be assigned followed by ENTER.
For example, to change ANI0 Units (A298) from PERCENT to gallons per minute (GPM):
P A298
Values entered with the PUT command P must be formatted as follows:
In general, all modification inputs are limited to the first ten characters of the field.
For B data type parameters, the value entered must be between 0 and 255.
For L data type parameters, the value must be 1 or 0.
All responses are completed by pressing ENTER.
Pressing ENTER after pressing P automatically recalls the last database parameter.
Pressing N after pressing P causes the next parameter of the same data type to be displayed. (The
NEXT command N only works with index numbers below 256.)
