MAP Technology Using Luminex 100 IS 2.3 Software
PN 89-00002-00-071 Rev. C 5 - 7
The DD temperature measures the doublet discriminator temperature.
DD temperature shifting indicates a need for system recalibration. If
you have not calibrated, the arrows showing the temperature range
for the DD temperature both appear at the bottom of the
thermometer, and the thermometer appears in red. An out-of-range
temperature logs an error, but does not halt the acquisition.
For information on setting the XYP instrument heater temperature,
see page 5-45.
The Command List displays commands associated with batches,
new advanced batches or multi-batches loaded for processing on the
system. The Command List shows the status of each command as the
system processes it, and whether the command completes
successfully or fails. Figure 5-5 shows that the first two commands
were successful, the third command is running, and the rest of the
commands are pending. Figure 5-6 shows that the third command
failed.
Figure 5-5. Command List Section of the Run Batch Tab
Figure 5-6. Command Failure Notation in the Command List
Errors are recorded in the Message Log on the Diagnostics tab. See
page 5-9 for more information about the Diagnostics tab. Double-
click on failed commands in the Message Log for additional
information. You can right-click a highlighted row to copy data to the
clipboard or clear the batch from the screen.
